Data Structures in Clojure: Singly-Linked Lists

About this Series

This series is about the implementation of common data structures. Throughout the series we will be implementing these data structures ourselves, exploring how they work. Our implementations will be done in Clojure. Consequently this tutorial is also about Lisp and Clojure. It is important to note that, unlike the standard collection of data structures found in Clojure, which are persistent, ours will be mutable.

To start with, we will explore a linked list implementation using deftype (more on this later) to define a JVM class from Clojure-land. This implementation will be expanded to include in-place reversal. Finally we will utilize Clojure’s built-in interfaces to give our linked list access to some of the methods Clojure provides.

Basic Requirements

While this is a tutorial, some working-knowledge of Clojure is assumed. We will not cover setting up an environment for development or basic introductory Clojure subjects. If you are looking for an introduction to Clojure itself, consider Clojure From the Ground Up. However, no knowledge of Java or previous experience implementing these data structures is otherwise required.

Some background with recursion will be beneficial. Most of the methods we implement will rely on recursion because it is a concise and idiomatic choice for many of these algorithms. That said most of the examples should be fairly easy to follow even without a lot of experience with recursion.

Linked Lists

Linked lists are a simple and common data structure. While being simple, they can be surprisingly subtle. This makes them a good choice for an introductory series on data structures and in fact our initial implementation will be used again later when we explore hash tables (one potential use for linked lists). They are also important with regard to Lisp because S-expressions can be derived from linked lists. This is a topic we will explore more closely in a future series.

Basic Structure

Singly-linked lists are composed of links or nodes, where each node contains some data or cargo and a next pointer. The next pointer points to the next node in the list or some empty value, e.g. nil, indicating the end of the list. A list of three nodes might look something like this:

In the above example the values “foo”, “bar”, and “baz” are all cargo. While the arrows are pointers to the next node in the list. The last node does not point to anything and instead holds nil as a terminating value. This will be the basic structure of our singly-linked list implementation.

Performance Characteristics

Linked lists provide extremely efficient insertion and deletion at the head of the list. These operations are O(1). Additionally, inserts and deletes into the middle of the list can be performed in constant-time provided a reference is kept to the node proceeding the node to be operated on, otherwise this is an O(n) operation. Inserts and deletes at the end of the list can also be performed in constant-time if the last element is known by some reference.

Our implementation will not provide any but the first performance guarantee, in the interest of simplicity. However, this implementation could fairly trivially be extended to a doubly-linked list to provide the aforementioned benefits.

Applications

While linked list are an excellent choice for situations where an algorithm interacts frequently with the head node or dynamic list size is desired, arrays and dynamic arrays provide a different set of advantages and ultimately a linked list is a trade off.

For instance, linked lists can be used to implement a Last-In First-Out stack in a fairly simple manner. Given the fact that appends to the head of the list are cheap, the push operation is inexpensive. Similarly, the pop operation is cheap–both of these methods are constant time.

That said, where random access is needed, a linked list may not be the best candidate. This is because we always have to traverse the list from the head unlike an array, where knowing the index ahead of time gives us efficient, near-constant lookups.

Variations

Linked lists come in various flavors. Generally when we say linked list, we mean a singly-linked list, which is what this article will focus on. It is worth mentioning there exists other variations which are beyond the scope of this tutorial.

Types in Clojure

defrecord and deftype

Before we get started, we should briefly discuss methods for defining custom types in Clojure, i.e. JVM classes. There are two:

(defrecord Foo [])

and

(deftype Foo [])

For this tutorial we will be using deftype. Records, via defrecord, should be preferred for application-level data modeling. Records provide map-like objects with faster access to their fields and which can implement custom interfaces and protocols. Whereas deftype is a superset of defrecord and does not provide accessors, equality, and default interfaces. Because we are interested in defining our own data structures, we will prefer deftype here.

Basic Implementation

Node Class

Now we will get started with our singly-linked list implementation. Recall that our list will be made up of links or nodes. These nodes will have two fields, a data field, which we will call car (you can think of this as short for “cargo”), and a next pointer field, which we will call cdr. (If you are curious about the nomenclature, this bit of Lisp history is relevant here.)

It seems like a class called Node might be a good way to encapsulate this structure. Let us go ahead and outline a Node type with deftype:

(deftype Node [car cdr])

Notice that our binding vector contains two symbols, car and cdr. Under the covers, these will become fields on the JVM class, of the same name. If we were now to use our type from a REPL we would be able to see how these fields work in practice:

=> (def node (Node. "foo" nil))
=> (.car node)
"foo"
=> (.cdr node)
nil

To construct a new Node instance, we use the the name of the class suffixed with a period. This is a shortcut for telling Clojure to give us a new Node object. We could also use (new Node "foo" nil), to the same effect.

With our newly constructed object, we can access its properties directly. As we can see, (.car node) returns the expected value of "foo". Likewise (.cdr node) returns nil.

We now have a singly-linked list of one element in length. Our last element terminates with a pointer to nil, indicating the end of the list. This is looking good so far. But we probably will not be satisfied with lists of only one node in practice, so we should think about how to encapsulate lists of many nodes.

One way we can approach this, without writing any additional code, is to simply nest invocations of the Node object. What if we do something like this:

=> (def linked-list (Node. "foo" (Node. "bar" (Node. "baz" nil))))
=> (.car (.cdr linked-list))
"bar"

Cool! That worked. By nesting constructions of the nodes, we built a linked list with multiple elements. This is pretty neat, but there’s actually a problem with our implementation as it sits: how do we update nodes?

When we use deftype to set up up our classes, they get compiled down to JVM classes. During this process the fields are set up as final. This effectively makes them immutable. In Clojure-land, this is a perfectly sane default. But not all data structures lend themselves to these kinds of restrictions. Not only that, but one motivating factor for defining custom types is performance. Sometimes, for performance reasons, we want mutability. Some algorithms are just faster or simpler when we can mutate data in place. Because of this, we have two options for exposing our fields as mutable.

The metadata ^:volatile-mutable and ^:unsynchronized-mutable, will yield mutable fields. While the particulars of these two options will not be covered here entirely, essentially ^:volatile-mutable will compile the field with the volatile modifier. This means that set operations over these fields are guaranteed to be visible to other threads immediately upon completion. Whereas ^:unsynchronized-mutable specifies a field which does not make this guarantee.

We will use the volatile option for the sake of simplicity.

(deftype Node [^:volatile-mutable car ^:volatile-mutable cdr])

Okay great! We can now modify the values of the car and cdr fields on our objects. But there’s actually another lurking problem here.

=> (def node (Node. "foo" nil))
(.car node)
IllegalArgumentException No matching field found: car for class Node
clojure.lang.Reflector.getInstanceField (Reflector.java:271)

Uh-oh. What happened? Well, when we made our field volatile, we also made it private. It is no longer accessible from the outside world. These fields will have to be accessible from outside the class if our list is going to be useful. What we can do here is expose their values via getter methods. At the same time we will also define methods for setting these values from outside the class. Let us go ahead and write those now.

(definterface INode
  (getCar [])
  (getCdr [])
  (setCar [x])
  (setCdr [x]))

(deftype Node [^:volatile-mutable car ^:volatile-mutable cdr]
  INode
  (getCar [this] car)
  (getCdr [this] cdr)
  (setCar [this x] (set! car x) this)
  (setCdr [this x] (set! cdr x) this))

Let us take a minute to talk about what we have done here. First we added an interface called INode. This defines an interface for our class. An interface is a collection of functions that can be applied to a type which implements that interface. Again we won’t cover this in much depth here, however from Clojure definterface provides this facility for us.

With our INode interface, we define our methods on the Node type. Note that the this reference is implicit in the context of definterface, so it is not a listed parameter of our interface methods. But because the reference is needed from within our class, we explicitly define it.

Finally we setup our getters and setters. These are pretty straightforward. set! implicitly understand its context and therefore only needs a field symbol and a value to bind it to. Here is what we have now:

=> (def node (Node. "foo" nil))
=> (.getCar node)
"foo"
=> (.getCdr (.setCdr node "bar"))
"bar"

At this point our Node is starting to shape up. Not only can we define a list of nodes but we can alter them later on and get meaningful data back from them. This is really all we need to build useful linked lists.

Now let us extend our interface a bit. Say we want to reverse the ordering of our linked list so that (.getCar linked-list) actually returned “baz”?

Reversing a Singly-Linked List

It turns out there is an efficient, in time and space, way to do just that. Returning to the original description of a linked list, we recall that nodes have two values: a cargo and a next pointer. So to reverse the list, perhaps all we need to do is start with the head node and swap it with its neighbor? We could then continue on to the next node in the list until we ran out of nodes.

If we consider a simple list of two elements:

We can say that we would like a’s cdr value to hold a pointer to b and for b’s cdr value to be nil. In essence, we want to switch the two nodes. This seems pretty straightforward. Here this will work. But what if we have a slightly longer list? Will the same approach work for a list of three elements?

This introduces a slight complication. If we were to have a list of three elements in length, what happens after we switch the head node with its neighbor? All would be fine until we went to select the next node, which would actually be the first node. We need to ensure that we do not step on ourselves as we traverse the list.

One approach here is to introduce an accumulator which ultimately will become the new head of the list. With this accumulator we can cons the current list’s head on it. And then the cdr of the current head, followed by the cdr of the cdr of the head, and so on, until we reach a null cdr. At this point we would have a completely reversed set of node elements collected in our accumulator. All we would then do is return the accumulator.

Now we will implement this scheme in our reverse method:

(definterface INode
  (getCar [])
  (setCar [x])
  (getCdr [])
  (setCdr [n])
  (reverse []))

(deftype Node
  [^:volatile-mutable car ^:volatile-mutable ^INode cdr]
  INode
  (getCar [_] car)
  (setCar [_ x] (set! car x))
  (getCdr [_] cdr)
  (setCdr [_ n] (set! cdr n))
  (reverse [this]
    (loop [cur this new-head nil]
      (if-not cur
        (or new-head this)
        (recur (.getCdr cur) (Node. (.getCar cur) new-head))))))

Let us pick apart of the reverse method by stepping through it. Our main goal here was to start with the head node and treat it as though it were the tail, persisting whatever value its cdr held, assuming it was non-nil, and then cons each successive node’s car onto this new head. In this way we reverse the list. To do this we use Clojure’s loop construct to recursively move through our nodes, passing over each one by one.

We start by defining cur and new-head in our loop. new-head is what we will eventually return as the head node, it’s our accumulator. On the first iteration of the loop, it will point to nil. This is because our linked list is null-terminated and this will serve as a sentinel for the tail node. We then bind cur to the value of head.

We now check for cur to be nil. This is our base case, the condition under which the recursive loop will terminate. If we have any nodes this check will fail and we will drop down into our second branch of the conditional.

Here we do two important things. First we make good on our strategy of consing the head node onto an accumulator, new-head. At this moment in time, new-head points to nil. Take careful note here, this is important because our list terminates with that value and therefore this defines the final node in our soon-to-be-reversed list. cur’s cdr value now points to nil, whereas before it pointed to the node that held “a”. The second thing we do is set new values for the second iteration of the loop: new-head becomes the value of (Node. (.getCar cur) new-head)) (i.e. a new node containing “b”), cur becomes the value of (.getCdr cur) (i.e. the node containing “a”). We recur with these values.

So where does this leave us? We are entering the second iteration of our loop. Our loop values have changed and we once again check if cur is nil. In fact it is not (it is the node containing “a”). That puts us in the second branch. Once again we set the cdr of cur to new-head. Think about what new-head points to: the value of setting the cdr of the the head node to the previous value of new-head, i.e. nil. In other words, it points to a sublist of one element. That element was the first node of our original list. We are going to set that value as the cdr of the cur node, which is the node that holds “a”. Again we recur.

This is the final iteration of our loop. This time cur’s value is in fact nil. Our linked list is reversed. Time to give it a try:

=> (def linked-list (Node. "b" (Node. "a" nil)))
=> (.. linked-list getCar)
"b"
=> (.. linked-list reverse getCar)
"a"

Great. It works! There is one caveat to this approach: we originally said that there was a solution that was efficient in both time and space. While that is true, our implementation is not efficient in terms of space. Because we copy the list instead of reassigning the node’s pointers, we end up consuming more memory than necessary. To remedy this we could instead change the node’s pointers in place.

(deftype Node
  [^:volatile-mutable car ^:volatile-mutable ^INode cdr]
  INode
  (getCar [_] car)
  (setCar [_ x] (set! car x))
  (getCdr [_] cdr)
  (setCdr [this n] (set! cdr n) this)
  (reverse [this]
    (loop [cur this new-list nil]
      (if-not cur
        (or new-list this)
        (let [cur->cdr (.getCdr cur)]
          (recur cur->cdr (.setCdr cur new-list)))))))

However this is slightly dangerous if our linked list is bound to a var such as linked-list. Since the original pointer bound to the var will become the tail of the list and references to the rest of the list will not be accessible. For simplicity we will not take that approach here.

Clojure Interfaces

Up until now we have used the methods we defined ourselves exclusively to manipulate our custom type. While there is nothing inherently wrong with this approach, it does mean we have been eschewing the use of Clojure’s API. One thing we might want to be able to do is call methods like first and next over our linked list.

If we try this now we will get an error that informs us our object does not participate in the ISeq interface. Indeed this is true and it is also something we can fix. Let us implement a generalization of the seq interface via clojure.lang.Seqable.

(definterface INode
  (getCar [])
  (setCar [x])
  (getCdr [])
  (setCdr [n])
  (reverse []))

(deftype Node
  [^:volatile-mutable car ^:volatile-mutable ^INode cdr]
  INode
  (getCar [_] car)
  (setCar [_ x] (set! car x))
  (getCdr [_] cdr)
  (setCdr [_ n] (set! cdr n))
  (reverse [this]
    (loop [cur this new-head nil]
      (if-not cur
        (or new-head this)
        (recur (.getCdr cur) (Node. (.getCar cur) new-head)))))

  clojure.lang.Seqable
  (seq [this]
    (loop [cur this acc ()]
      (if-not cur
        acc
        (recur (.getCdr cur) (conj acc (list (.getCar cur))))))))

Here we have implemented clojure.lang.Seqable. Our goal in defining the seq method is to return a sequence that represents our object. So in the case of our linked list that would be a sequence of all of our nodes. Each node is referenced by the current node forming a list. We use concat, in order to preserve the correct ordering, build up an accumulator list. Ultimately we return this accumulator. This is what we get when we call seq over a linked list instance now. Let us give it a shot.

=> (def linked-list (Node. "foo" (Node. "bar" (Node. "baz" nil))))
=> (seq linked-list)
("foo" "bar" "baz")
=> (first linked-list)
"foo"

By implementing the seqable interface we have access to some of Clojure’s built-in methods. Notably our object can now be cast to a sequence which means first, next, and rest will work. While this is certainly handy, there is a caveat.

Sometimes clojure.lang.Seqable will not be enough to satisfy the ISeq interface. In this case, we will have to implement clojure.lang.ISeq explicitly. Furthermore, Clojure objects implement more than just the sequence interface. So you may find some built-in methods will complain and throw errors.

Completeness

In order for our object to be a “complete” Clojure datatype we would have to implement a number of interfaces. This is largely outside the scope of this tutorial and we will not attempt that here. But one additional interface we might consider is clojure.lang.ITransientCollection and its associated methods.

Also note that Clojure interfaces need not be implemented comprehensively. That is to say that you can implement any number of methods they provide and not necessarily all of them. That said, generally it is a good idea to implement all of them or we may find we end up with strange errors such as AbstractMethodError, indicating a method that the interface provides was not implemented.

Conclusion

This is the end of our exploration of a linked list implementation. While our implementation is simple, it is correct and usable. By utilizing Clojure’s deftype we have created a proper JVM class. This class could even be used from other JVM languages, such as Java.

Additionally we explored the implementation of a fundamental linked list operation: reversal. Our solution is a recursive solution that builds up a new list but successively taking nodes from the head of a given list and appending those to the accumulator list.

Finally we took a look at how we can take advantage of some of Clojure’s built-in methods by implementing the clojure.lang.Seqable interface. While this does not qualify as a comprehensive datatype from the perspective of Clojure, it is nonetheless useful.

Our implementation could be used to implement a variety of more complex data structures, some of which we will explore in the future. However one simple exercise is to leverage what we have here to build a simple stack. Try to implement the push and pop methods, where push takes a value and stores it in a node appended to an underlying linked list and pop takes the first node of that same list, returning its value.

=> (def s (stack))
=> (.push s "foo")
=> (.push s "bar")
=> (.pop s)
"bar"
=> (.pop s)
"foo"
=> (.pop s)
nil

Future Posts

Now that we have a linked list, we will use this linked list to build a hash table. The next post will introduce hash tables and cover an implementation that uses separate chaining and dynamic resizing. Stay tuned!
